HD-C, aircraft refueller
IBC
with CHS chemical hose assembly
ERV-CR
"CR" Rubber Expansion Joints - ballast water treatment skid
ERV-G 80.TW
ERV-G Rubber Expansion Joint with TW flanges DIN 28460 for installation to tankers
ERV-GR ... ZS
"Green Band" Rubber Expansion Joints with limiters in chemical pumping system
Slimline 21 red
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.
LNG Refuelling
LNG Safety Break SB-LNG VL und SB-LNG FL
ZVA Slimline 2 GR
blue scuffguard, blue produc sleeve, guard no. 4
ELAFLEX Hamburg
Delivery trucks, loading ramps
FHD 50 special type HIFR
(helicopter in flight refuelling)
Example of a marking of test data (hydrostatic test) of a hose assembly
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
Tank truck and trailer with HD 45 hose reel, ZV 500 nozzle
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Dispatch
Hot stamping process, TW coupling part
Underwing refuelling, HD-C hose assembly
Hydrant dispenser
IBC unloading
Female hose coupling MC 38-S60 SS (with Spannfix clamps). Direct connection of a hose assembly to the IBC.
V-St 50 SSE
Male threaded hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers
Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO UL with EA 866 scuffguard, LPG 16 hose
VR Hose Reel Spring Rewind, ZVA Slimline 2 GR blue
for active Vapour Recovery (VR) for gasoline fuels
Nozzles and hose assemblies for the forecourt
ZVA Slimline 2, ZVA Slimline 2 GR, Slimline hose assemblies
ZV 500 DDC, ZVA 32 DDC, hose assembly with DDC-M coupling
Refuelling of construction site machines from the road tanker: only one hose reel, choose between two nozzles (ZV 500 for bulk, ZVA 32 automatic nozzle up to 200 l/min)
Elaflon Plus FEP 75, MK-A 80 SS
Loading and unloading of chemicals. TW coupling with active safeguard lever
MK 80 Ms
TW coupler of brass, to EN 144260-6 with 3" female BSP connection
Safety Swivel Break
SSB 16 SS
GasGuard nozzle GG 1 DN, hose assembly, nozzle boot NB-GG
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapters Storz / Guillemin Storz C SS/Vi x VK 50 SS/Vi, Storz C SS/Vi x MK 50 SS/Vi, GK 50 SS/Vi x VK 50 SS/Vi, GK 80 SS/Vi x VK 50 SS/Vi
ELAFLEX refuelling equipment:
Quality is in the detail.
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapter Rail Tanker Dischharge Coupling KWK SS/Vi x VK 50 SS/Vi
