Hose assembly with MKX 75 SS and VB 80 SS
TW female coupler with Spannfix clamp, plug
Elapharm EPH 38 OHM-G with CF hose tail DIN 32676, free of dead spaces
LNG Refuelling
LNG truck refuelling with 'N-LNG' Nozzle coupled to fuel, LNG 25 fill hose assembly with cover, bonding cable
AVKI 38 SSE
Camlock male adapter. Material: stainless steel with universally resistant PFA coating (red)
Production plastic parts
Injection Molding
NB-ZVF 50 SR, ER 583 PTL
Nozzle boot f. ZVF 50 with additional spout retainer
Colour production: mixer
UTS hose assemblies
Polypal Plus universal hose / Polypal Oil universal hose with oil resistant cover
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
Camlock hose couplings: system comparison
Easyloc from Elaflex with automatically secured levers.
Hose assemblies and Rubber Expansion Joints for the chemical industry
ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad
L.P.Gas petrolstation, GG20, Slimline, ZVG 2 EURO UL
Lightweight Gravity Discharge Road Tanker Hose LG 4"
with TW coupling (VK 100)
LNG Refuelling
N-LNG Nozzle, push handles to couple
ERV-G AF
Suitable for piping systems of aviation refuelling or dispensing vehicles in accordance to EN ISO 1825/EI 1529. Suitable for all aviation fuels.
DDC-V 80 F
Dry Disconnect Coupling for Epoxi resin loading - with sensor
ZVA Slimline 2 GR
Automatic nozzle with vapour recovery, flowrate up to 45 l / min.
ZVA Slimline 2, ZVA Slimline 2 GR (Special type with PowerPerformer)
AMX ammonia hose
rail tanker Loading/Unloading
RS 1 x 11/2 SS
Reducer Female/Male
Heating oil delivery: ZH 50 nozzle, HD reel hose
ELAFLEX Hamburg
ERV conductivity test
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Road tanker hose assembly
with VKC 75 SS (TW male coupling stainless steel, one part, with Spannloc clamps, K-Ring), dust cap VB 80 SS & chain
Petrol station in Singapore
ZVA Slimline 2 nozzle with Splashguard, SSB 16 Safety Break, Slimline hose assemblies
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (German)
Slimline quality dispensing hose for the forecourt
UTL 50 universal chemical hose assembly and TW female coupler MKC 50 SS
IBC loading and unloading
MannTek DDC-M 50, FWS 50 PTFE
