Saturated steam hose fitting SMS 19-3/4" SS/SS
completely of stainless steel, with self-securing bolts and nuts; possibility to attach stainless steel anti-kinking spirals KSS-SD
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
Stainless steel couplings with PFA coating, type "...SSE"
Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
Road tanker connection - MK 50 Ms, VB 50 Ms, Chain
Anti theft protection with padlock
HD 63 C NEON, TW 75 E NEON
'NEON' type with reflecting bands or NEON marking in spiral form
ELAFLEX Hamburg
New narrow aisle stock (2018)
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
Safety Swivel Break SSB 16 SS of stainless steel f. ZVA HV for AdBlue®
new design
LG 2" hose assembly for gravity discharge, respectively for vapour balance
V 16-3/4"
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, blue.
H2 Cover Hose 'CH-H2 38'
Nozzle Thread
Type PCS 50 (Polypal Clean DN 50 mm)
Rubber Expansion Joint ERV-G 80.16
YELLOW BAND expansion joints suitable for petroleum based products with aromatic content up to 50%, fuels (ethanol content up to 85 %), aviation fuels, town gas and natural gas except liquefied petroleum gas. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.
ZVA LV for AdBlue®
Urea solution filling of cars and light transporters
Rail tanker unloading of petroleum based products
LTW 75 (hose), MKX 75 ('TW' female coupler with Spannfix clamps), Adapter KWZ x VK 80 (51/2" x 'TW'-male coupler)
Tank storage: manifold with DDC Dry Disconnect Couplings, TW hose assemblies
ELAPHARM hose assemblies, applications
IBC unloading
Coupling of chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-reducer RS 60 x 2 SS, directly attached to IBC.
Oasis CNG refuelling equipment:
Ultra Fast Fill System (Diagram, German)
ELAFLEX Hamburg
ERV, assembling limiters (tie rods) with rubber bushings
Hose assemblies
for saturated steam, chemicals, petroleum based products
Quality in the detail: valve assembly of a ZVA Slimline 2 petrol station nozzle
M 19-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 19 SF hose Sulfur Free, black.
Road tanker hose reel, made by Elaflex Italia
with LPG hose assembly
V 16-1" cr
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, black.
Unloading LNG road tanker
DCC Dry Cryogenic Coupling
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting: melting
Ship bunkering
'Yellow Band' collapsible high
IBC metal container; UTS hose assembly
