Elapharm EPH 25

ELAPHARM electrically isolating ' I ', blue cover. Corresponds to DIN 26055-3 / EN 16820, Type A. FDA conform. Homogeneous elastomer hose construction with smooth, white Teflon® PTFE liner.

M 63 2½" SS, TD 76/63 PTFE, Spannloc SC 63 Al

Hose coupling with female thread, Spannloc aus Aluminium

Ship bunkering

HD hose assembly on dispenser vehicle

Anti-Kinking Spirals 'KSS' and 'KSS-SD'

The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings

GasGuard LPG nozzle GG1E

eoconomic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.

Cylinder Valves (Tank Heads)

TH104

Ship bunkering with LNG

CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media

Ultra Fast Fill Quick Coupler 350 bar

for Hydrogen

MC 38-11/2" Ms

Female hose coupling for hoses, brass, with Spannloc clamps

ERV-CR ... ZS

"CR" Rubber Expansion Joints; water purification plant

ELAFLEX Hamburg

DDC-V 50 F Aseptic

MannTek Dry Disconnect Coupling, DN 50, stainless steel, with Aseptic flange

AdBlue® urea solution, road tanker:

DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel

Hose assembly TW 75 with MKX 75.80 Ms

TW hose with TW female coupler, two piece

Elaflex hoses

TW, PTFE, LPG, FEP, UTS, PCS, CHS

MannTek, DEC-M 38, DCC-M 50, DGC-M 80, DDC-M 50, DDC-M 80, DAC-M 65, DAC-V 65

Rubber Expansion Joint ERV-G 80.16

YELLOW BAND expansion joints suitable for petroleum based products with aromatic content up to 50%, fuels (ethanol content up to 85 %), aviation fuels, town gas and natural gas except liquefied petroleum gas. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

HD 100 C NEON, HD 10 C sensing hose

Type HD-C, aviation hose

ERV-CR

"CR" Rubber Expansion Joints - installation in sewage plant

Slimline dispensing hose SF (sulfur-free)

Fuel producers spend considerable effort in fulfilling the maximum allowed sulfur content. Rubber compounds of this hose type are free of sulphur – ensures that the sulphur content of the fuel is not increased, even if the medium remains for a long time within the hose

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapter Sight Glass SG 2" SS/Vi with MK 50 SS/Vi and VK 50 SS/Vi

ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid

and Sight Glass SG 1 Al / Slimline dispensing hose

ERV-GR ... ZS

"Green Band" Rubber Expansion Joints with limiters in chemical pumping system

Unloading: MK couplers with DDC-V 80 adapter

KW bronze corrugated pipe with cathodic protection

Cathodic protection flexible pipe connector (bronze corrugated pipe) for electrically insulating, cathodically protected installations. Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps - and directly underneath the dispensers

ELAFLEX Hamburg

CAD construction

Elaflon PTFE 38 hose assembly with crimped fitting

Slimline 21 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

CHS 50

Lilac Band chemical hose with helix, DN 50

Polypal Plus 50 universal hose

with SFC 50 SS / SS hose flange (hose tail, swiveling flange and Spannloc clamps of stainless steel)
