Elaflex Pacific (Australia)
Construction
Production MannTek, Sweden
oasis TH Tank Head Valves, CNG trailer
Drum unloading chemical industry
UTS hose assemblies with Easyloc cam locking couplings
Connection road tanker to trailer: TW hose assembly, DDC Dry Disconnect Coupling
Road tanker Sweden
large reel with HD hose assembly, DDC-V (Dry Disconnect Coupling, tank unit) and DDC-K (caps)
Lube oil loading of a ship
TW 75 hose assembly, TW couplings
HD-C aircraft refuelling hose
TW 75 E
HB 50 ST tar spraying hose
Pressure hose for road construction machines, especially for hot bitumen and heavy heating oil. Temperature range: - 25° C up to + 220° C. Meets EN 13482, Type 2 SB/B (DN 19 and DN 32 analogue).
ELAFLEX Hamburg
ERV marking after test
TGN 2" Al (TGN 50 Al)
Tank truck flange aluminium, one end flange to DIN 28462, other end male BSP thread.
DDC-M 100 SS, Elaflon Plus FEP, VC 100-4" SS
Terminal loading / unloading of chemicals with Dry Disconnect coupling and universal hose
ZVA Slimline 2 nozzles with splashguard, Slimline hose assemblies
Refuelling at a petrol station in the United Arab Emirates
Unloading petroleum products at the service station (road tanker to UST)
LTW hose assembly, MK 80-32° Ms couplers with bent lever. The lever shall always be fully closed for safety reasons. For applications with limited room.
VR Hose Reel Spring Rewind red, ZVA Slimline 2 GR green, ZAF 2
for active Vapour Recovery (VR) for gasoline fuels
Elaflex LTW hose assembly, Matterhorn
Supply of the mountain top station via IBC unloading
ERV TA:
ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.
ELAFLEX seals:
Quality is in the detail.
Aircraft refuelling: MannTek sampling unit in hydrant system
Nozzles and hose assemblies for the forecourt
ZVA Slimline 2, ZVA Slimline 2 GR, Slimline hose assemblies
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
ERV with black, conductive PTFE lining 'TA OHM'
Hose Reel Spring Rewind
HD 25 C, ZVA 25 AF red, GKG 25, EKG 1200
AN Rd 78 SS
Welding nipple with foodstuff thread, stainless steel
ERV-G 80.TW
ERV-G Rubber Expansion Joint with TW flanges DIN 28460 for installation to tankers
Aviation Dispenser
with VHD 100 C and HD 75 C Neon hose assemblies, SFC 100 TW and SFC 75 TW hose couplings
SG 1" 1x0 Al
Sight Glass with propeller, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.
MK 100-90° SS
Special type with bent lever
GasGuard nozzle GG 1 DN, hose assembly, nozzle boot NB-GG
Road tanker with open hose reel, HD hose assembly, ZV 500 nozzle
Hose with SC 50 SS Spannloc stainless steel clamps - corrosion protection against road salt
