ZVG 2 K (Korea)
uncoupling from J 15 filler connection
Solvent filling with integrated vapour recovery in the nozzle
ZVA 25 GR, UTS hose assemblies
ZVA LV for AdBlue® with SSB 16 LV SL 16 for AdBlue® hose assembly (blue)
AdBlue
ZVA Slimline 2 with reduced spout and Slimline hose
here: for gasoline, use in countries without vapour recovery regulation
Hose Trolley for terminal operations (bunkering, cargo and refinery)
Hose Trolley HTR-T
PSB Pump Safety Break for High Hose Dispensers
Picture shows separation of the Slimline hose assembly after a drive-off accident
Hot stamping process, production TW coupling parts
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling hall, meterial logistics
Adapters / couplers for vehicles fighting dangerous goods incidents:
Plugs and Caps MB 50 SS/Vi, VB 50 SS, VB 100 SS, BK 2" SS/Vi, BK 3" SS/Vi
HD-C, airport depot
Underwing couplings with HD-C hoses for bottom loading of aircraft refuellers at airport depot
ROTEX 80.16
Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative
ERV-G
Ship engine room: 2 Yellow Band Expansion Joints mounted together for extra permissable movement
ZVG 2 K (Korea)
with EA 866 scuffguard / nozzle talker
Section view of a CSB 21 COAX Safety Break
ELAFLEX Hamburg
Assembling ERV small DN
ELAFLEX Hamburg
Nozzle stock, ZVA Slimline 2 GR
ERV RG:
Angular limiter
Safety Swivel Break
SSB 32
ERV-G ... TW
Aircraft refueller
DAC-V 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading
Road tanker with hose reel -
Quick change system between ZV 500 and ZVA 32 nozzles via DDC Dry Disconnect Coupling
Tank storage, mixer: LTW hose assemblies
Pipe with AVKI 50 SS, hose assembly with AVKX 50 SS
'Camlock' stainless steel female and male coupling to EN 14420 - 7
MB 50 TS SS Lockable fi ll pipe coupling
with VK 50 SS
ERV-R 80.16 SS TA
Red Band Rubber Expansion Joint with "TA" PTFE lining
GasGuard LPG nozzle GG1EH
used for industrial refueling / attended refueling. With hybrid nose piece − low lever force. Release volume on valve closure: 1,7 cm³.
GasGuard LPG nozzle GG20DN
With long connector nut to access 'hard to reach' fill points. "DN": suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure : 1,7 cm³.
ZV 400, HD hose assembly on road tanker
ERV-OR
"Orange Band" Rubber Expansion Joints, road tanker
Hose Connection with TW coupling, TSG 3" Sight Glass
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
