Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (German)
Boat refuelling, ZVA Slimline 2 GR
ContiTech Production ERV
Long term elongation / compression testing
ELAFLEX Hamburg
Assembling Spannfix hose clamps
Hose Reels electrical rewind system yellow
for water
FWS composite hose / hose assembly
Type FWS PTFE with male threaded fitting VPH-SS
ZVA Slimline 2 GR, hand
scuffguard and product sleeve green, Slimline hose assembly with Colour Sleeve green
Simultaneous Refuelling/Filling of Diesel and AdBlue®
Picture 3
ZVA LV for AdBlue® with EA 075 LV
Urea solution (DEF, ARLA 32) for Light Vehicles
SSB 16 Safety Break: Abriss
MK 80-90 SS; MK coupling stainless steel with bent lever 90°
TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
Swivels DG of stainless steel
Swivels serve to avoid hose torsion (increase of life span) and help for easier handling
DGC-V 50 F SS for L.P. Gas, PN 25/40
Dry Disconnect Coupling with flange connection, DN 50, stainless steel, with rubber dust cap
ZVA Slimline 2 GR, SG-COAX, ZVA SLimline 2, SG 1" Al
Multi Product Dispenser with / without vapour recovery; nozzles with Sight Glass
DCC Dry Cryogenic Coupling for LNG
Coupling process
Alternative fuels: DME Dimethyl Ester
DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly
ELAFLEX Hamburg, marking tested hose assemblies
Polypal Clean, MX 50 SS
Adapter: MK 50-45° SS x VK 50 SS
The lever is bent to enable lever arrest (safe position when coupled)
Offshore FSRU (Floating Regasification Unit), connector for gasoil sludge / seawater
DDC-V 150 F
HD-C aircraft refuelling hose
VHD 63 C NEON
Hose Reel Spring Rewind
HD 25 C, ZVA 25 AF red, GKG 25, EKG 1200
TS 80 lockable cap vor VK 80 couplings
Swivel Flange and hose tail of stailess steel
SF 63.16 SS
ELAFLEX Hamburg
LMD 25 Blue Band solvent hose
without helix
Aircraft refuelling
Carter Underwing Nozzle, HD63C Neon, ZVF50, SC50Al, HD50C, Hose Bead BD50
ZVG 2 K (Korea)
LPG nozzle for vehicle refuelling with liquefied petroleum gas (propane, butane and mixtures) up to 50 l / min. Working pressure 25 bar. Test pressure 40 bar. Burst pressure > 100 bar. Temperature range - 25° up to + 70° C, 'LT'-Type down to - 40° C.
MannTek, DDC-M 50, DEC-M 38, DDC-M 80, DCC-M 50, DGC-M 80, DAC-M 65, DAC-V 65
V 16-3/4"
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, yellow.
