ZVF 50 AVGAS for aircraft refuelling

with ER 583

oasis TH Tank Head Valves, CNG trailer

GasGuard LPG nozzle GG30

LPGas nozzle with Bayonet connection according to EN 12806 - 2003 for the filling of commercial and passenger Autogas vehicles as well as mobile and small stationary storage tanks with propane and butane. New : 4-slot design to facilitate connection of the nozzle to the vehicle fill point. New nose piece design to reduce the released gas upon valve closure, incorporating improved gas release method to minimise the risk of splash back.

ZVA Slimline 2, black, guard 3 - detail view with new hold-open latch

ERV-R

"Red Band" Rubber Expansion Joints with limiters / pump station

PAL hoses for the chemical industry

UTS 200 hose assembly in chemical plant

Italy

ZVA Slimline TD

Automatic nozzle with special seals, for solvents / chemicals

LTW 75 hose assembly

with MKX 75.80 Ms

Manifold for filling chemical tanktrucks

UTS hose assemblies

ZVA Slimline 2 GR nozzle

with Coax hose assembly (one side open end, inner vapour hose visible)

Accessories and spare parts: Ground cable assembly, dust cap assemblies, spouts, strainer

ER 339, ER 494, ER 495, ER 587 JET PTL, EKG 1200, GKG 19, GKG 32, GKG 38-J, ES336.1

Polypal Clean hose

Vehicle refuelling with LPG (L.P. Gas, Autogas, Propane)

GasGuard GG1 ACME nozzle

Group picture

TW 100, DDC-M100 4", Hose Reel VR Spring Rewind System, ZVA Slimline 2 GR, ERV-G 1000, ERV-BR 300

Stainless steel couplings with PFA coating, type "...SSE"

Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components (English)

Oasis FV103 45° Fill Valve with NC 104 Nozzle, for CNG

Slimline quality dispensing hose for the forecourt

Adapter: MK 80-32° Ms x MK 80-32° Ms

Special type with bent levers. The lever is bent to enable lever arrest (safe position when coupled)

Slimline 21 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

Yellow Band hoses from Elaflex

Setting the standard for refuelling hoses

Road tanker hose assembly

with VKC 75 SS (TW male coupling stainless steel, one part, with Spannloc clamps, K-Ring), dust cap VB 80 SS & chain

ZVF 50 JET overwing refuelling

with HD-C hose assembly

Chemical Hose Reel with manual rewind system blue, UTS 50, ZV 400

for alcohol

Manufacturing warm forged parts

Example SC 150 Spannloc clamp

Nozzle boot NB-ZVF 50

for ZVF 50 Oberflügel-Zapfventile

SSB 16 LV

Safety Swivel Break, for ZVA LV for AdBlue^®. Calibration switch 10 l/min – 5 l/min

VC 75-3" SS / SS

Spannloc threaded hose coupling with BSP male thread / Spannloc of stainless steel

Unloading petroleum products at the service station (road tanker to UST)

LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
