Stock intake quality check – measurements

ELAFLEX Hamburg

ELAFLEX stock

Oasis BV708, 1" ball valves, isolation valves, CNG trailer loading

Rubber Expansion Joint ERV-G 80.16

YELLOW BAND expansion joints suitable for petroleum based products with aromatic content up to 50%, fuels (ethanol content up to 85 %), aviation fuels, town gas and natural gas except liquefied petroleum gas. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

Solvapal 32

Solvent hose to EN 12115 for most solvents, paints (also waterbased), water laquer, petroleum products, alcohols, alede hydes, esters and ketones. In short term operation also suitable for aromatic und chlorinated hydrocarbons.

MK-A 80 SS, TW female coupler with Active Safeguard Lever

connected: hose assembly with VKX 75.80 SS

ELAFLEX Hamburg

Commissioning / Pick by Voice

Rubber Expansion Joint ERV-G LT 80.16

YELLOW BAND LT expansion joints designed for low temperature applications for standard-conform petroleum based products, e.g. diesel, heating oil up to + 90° C, aviation fuels, petroleum up to + 60° C and gasoline up to + 40° C. Temperature (depending on medium) range - 40° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

ZVA Slimline 2, Splashguard, Slimline 16 hose assembly

Universal hose assembly

PCS 75 (Polypal Clean DN 75 mm) with MX 75-3" SS and DDC-M 80-3" SS Dry Disconnect Coupling

Colour production: mixer

UTS hose assemblies

ERV-R 100.16

RED BAND Rubber Expansion Joint for water, drinking water (DVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature range - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

Multi Product Dispenser with ZVA Slimline 2 nozzles, SSB 16 Safety Breaks with BS 16 Break Sleeves

Chemopal 50 mW

Chemopal chemical hose DN 50 with helix

ZVA 25 nozzle, Slimline hose assembly

Dispenser for truck refuelling

Elapharm EPH 25

ELAPHARM electrically isolating ' I ', blue cover. Corresponds to DIN 26055-3 / EN 16820, Type A. FDA conform. Homogeneous elastomer hose construction with smooth, white Teflon® PTFE liner.

Ship bunkering with LNG

Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling

FGN 2 St

Flange with male thread, steel zinc plated/chromated

TWD-TM coupling seal

PTFE encapsulated

ELAPAC FD flat sealing material

2 or 3 mm thickness, available as coil, standard size seal or in custom shape. An elastic flange seal for tank truck and tank plant construction etc., where rough sealing surfaces require a high adaptability, where flange seals should still have good flexibility to avoid pipe fractures or simple sealing materials because little or no force can be used to tighten the joint.

Bunkering ship: FHD hose assemblies

Yellow band aircraft refuelling hose, hose coupling with male thread, Spannloc aus Aluminium

HD 50 C, VC 50 SS, SC 50 Al

Transporter and school bus refuelling with LPG (L.P. Gas, Autogas, Propane)

GasGuard ACME nozzle

Urea solution filling for light vehicles - parallel to Diesel refuelling

ZVA AdBlue LV / ZVA Slimline 2

Section view ERV-R Rubber Expansion Joint

Elaflex Pacific (Australia)

Refuelling with ZVA Slimline 2 nozzle

Scuffguard, Product Sleeve and Colour Sleeve in grey special colour

Elaflon PTFE 50 with FFX 50 SSE/SS; PCS 25 with AMKC 25 SSE/SS

Universal hoses with PFA coated fixed flange and Camlock fittings. Spannfix / Spannloc stainless steel clamps.

Vehicle refuelling with LPG (L.P. Gas, Autogas)

ZVG 2 ACME nozzle, LPG 16 hose

Tecnopal chemicol hose assembly

on hose reel
