Media Library / Images

Pharma hose fittings

ELAFLEX refuelling equipment for LPG (Autogas, L.P.Gas)

Hose assembly TW 75 with MKX 75.80 Ms

TW hose with TW female coupler, two piece

EL 800 Earthing Strap with vulcanized copper strand

Electrically conductive bonding. Use for road tankers for petroleum based products, solvents, bulk tankers, forklifts, cable cars and cable Electro-Buses.

KSS-SD of stainless steel

for saturated steam hoses. These hose assemblies are subject to high wear. The main stress area for hose assemblies is also at the joint end is protected.

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Swivel assembling

KR 50

bend with VK 50 x MK 50, 60°

Ferrule threaded hose coupling M 19-1" cr

for petrol station dispensing hoses

ERV-CR

"CR" Rubber Expansion Joints - installation in sewage plant

Urea loading of a petrol station tank

UTS hose assembly, DDC-M 50 SS Dry Disconnect coupling

Elaflon PTFE

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

Slimline 21 blue

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

Rubber Expansion Joint ERV-G LT 80.16

YELLOW BAND LT expansion joints designed for low temperature applications for standard-conform petroleum based products, e.g. diesel, heating oil up to + 90° C, aviation fuels, petroleum up to + 60° C and gasoline up to + 40° C. Temperature (depending on medium) range - 40° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

ELAFLEX Hamburg

ELAFLEX stock

DAC-M 65

MannTek Dry Aviation Coupling

ELAFLEX Hamburg

Mini Installation instructions, on request

Hose Trolley

HTR-AF, HD 100 C NEON, HD 10 C

Ship bunkering with LNG

Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling

GW-G, FGN 4" SS, RS 4" x 3" SS, MK 80 SS

f. fire brigade dangerous goods equipment trucks

ERV VSR:

ERV with vacuum support ring. Ring of AISI 316 Ti , used when the vacuum resistance of the chosen ERV is not sufficient.

Type PCS, Polypal Clean

PCS 25, PCS 63, PCS 100

ELAFLEX Hamburg

Stock special flanges, pick by voice

ZVA Slimline 2, guard no. 8D, black scuffguard, red product sleeve, SL 16 hose assembly with red colour sleeve

AMX 50 PA

Ammoniac hose to EN ISO 5771 for water-free, liquid and gaseous ammonia.

Urea solution filling of a car: ZVA LV for AdBlue®

Vehicle refuelling with LPG (L.P. Gas, Autogas)

GasGuard GG30 BAYO nozzle with Bayonet connector and optional splashguard, LPG 16 hose assembly, ARK 19 Safety Break

Safety Swivel Break

SSB 16.0

SL 16 for AdBlue® hose assemblies

black or blue; specially made for urea solution (DEF, ARLA)

GasGuard LPG nozzle GG1E

eoconomic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.

KR 50 - 21/2", HD reel hose

Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors
