Cabinet of road tanker:
hose tubes, TW hoses, TW couplings
L.P.Gas road tanker
KSS-SD of stainless steel
for saturated steam hoses. These hose assemblies are subject to high wear. The main stress area for hose assemblies is also at the joint end is protected.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting
Coloured hose assemblies for the forecourt
Slimline 21, M 21-1" NR
V 16-3/4"
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, red.
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
HD-C, airport depot
Underwing couplings with HD-C hoses for bottom loading of aircraft refuellers at airport depot
MK 50 SS
TW female coupler, stainless steel
ERV-G Yellow Band rubber expansion joint, installation underneath a road tanker
AdBlue urea solution, road tanker:
DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel
V 19-1"
Male ferrule hose coupling EN 14424, reusable. Slimline 19 hose, black.
Storz Safety Couplings Type SHK
upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.
Slimline 21 blue
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.
Bellows ERV-GR (Green Band) without flanges, with VSD vakuum support spiral
VSD: to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571
Ship loading various media - STW 150 and UTS 150 hose assemblies
Hose Connection with TW coupling, TSG 3" Sight Glass
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
Flexible bronze pipe connectors
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
Hose Reel spring rewind red, SL 19 black, ZVA Slimline 2 green
ERV-BR 300
for abrasive Media
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 18
FHD 50 special type HIFR
(helicopter in flight refuelling)
ContiTech Production ERV
Testing UV resistance
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 ACME nozzle, LPG 16 hose
H2 Hydrogen
H2 25 D Hydrogen hose, SFC 25, MX 25, VC 25
Oasis SV 108 Sandwich Valves 1" on CNG trailer
ELAFLEX Hamburg
Visual quality checks
ELAFLEX Hamburg
Incoming goods / flanges
ELAPHARM Type EPH-OHM G
electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner. Clamp fittings, lining flared (free of dead spaces).
