UTL 50 universal chemical hose assembly with KSS anti-kinking-spiral
and DDC Dry Disconnect Coupling
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapters Storz / Guillemin Storz C SS/Vi x VK 50 SS/Vi, Storz C SS/Vi x MK 50 SS/Vi, GK 50 SS/Vi x VK 50 SS/Vi, GK 80 SS/Vi x VK 50 SS/Vi
SPANNLOC bolted safety clamps of stainless steel
SC 75 SS
MK 80-90 SS; MK coupling stainless steel with bent lever 90°
TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
ERV-G 80.TW
"Yellow Band" Rubber Expansion Joints; tank truck
SG 3" Rg
Sight Glass with 3" female/male BSP thread, gunmetal
Ferrule threaded hose coupling M 19-1" Ms
for petrol station dispensing hoses
Oasis CNG refuelling equipment:
Ultra Fast Fill System (Diagram, English)
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
ELAFLEX Hamburg
ERV assembling
Lightweight Gravity Discharge Road Tanker Hose LG 3"
with VX 75-3" Al LG
DDC-K 2 1/2" PE
Dust cap for DDC-V Dry Disconnect Couplings;
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation
Camlock cam locking couplings
top left – ELAFLEX standard version; bottom right – ELAFLEX EASYLOC version
TWD coupling seal
Slimline 19 black
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
Elaflon Plus PTFE 38
Filling of small containers for chemicals
Oasis HC208 Quick Coupler, CNG loading
Production MannTek, Sweden
ERV SR:
ERV with inner protection sleeve of stainless steel AISI 316 Ti to prevent abrasion of the rubber liner, i. e. for media containing abrasive components or to avoid cavitation. Please note : The nominal bore is reduced.
Stainless steel Hose Reel with pneumatic rewind system, FWS 50 PP
VB 50 SSE
TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
KR 50 - 21/2"
Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors
ElaSil® Silicone hose
ZVA Slimline 2 GR, Bügel 1, Product Sleeve blue, Coax hose assembly with Colour Sleeve blue
Camlock hose couplings: system comparison
right hand side - industry standard, with cable tighteners to fix levers. Left hand side: Easyloc from Elaflex with automatically secured levers.
ZVA Slimline 2 nozzles, ESB 16 Safety Breaks, Slimline hose assemblies
Paraguay
ERV-G 100 TW
Aircraft refueller
Fuel Grade Identification to EN 16942 for ZVA Nozzles
Type EK FGI - attach with Product Badge EK 145
Oasis TM106 Trailer Unloading Manifold, for CNG
Fluorflex FXD universal hose assembly
extremely flexible PTFE hose with maximum bending radius
