Locomotive refuelling
Dispenser, ZV 32 DB nozzles with Renk coupling
ELAFLEX Hamburg
Incoming goods / flanges
LNG Refuelling
LNG truck refuelling with 'N-LNG' Nozzle coupled to fuel, LNG 25 fill hose assembly with cover, bonding cable
Production MannTek, Sweden
ELAFLEX Hamburg
Assembling TW hose coupling with Spannloc clamps
Elaflon PTFE hose asemblies
Slimline 16 black
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
IBC loading and unloading
MannTek DDC-M 50, FWS 50 PTFE
ElaSil® Silicone hose assemblies
MK 50 SSE
TW female coupler. Material: stainless steel with universally resistant PFA coating (red)
ZVG 2 EURO UL
L.P.Gas nozzle for Autogas refuelling with propane, butane and their mixtures - with "EURO" connector; UL listed.
MK 80-90 SS; MK coupling stainless steel with bent lever 90°
TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
Rubber Expansion Joint ERV-CR 80.16
CR Expansion Joints for cold and warm water, swimming pool water, sea water, waste water (weakly sour or alkaline) also oil containing, cooling water with protective oils against corrosion, lubricating oil, grease and air, compressed air. Temperature range (depending on medium) - 25° C up to + 90° C, temporarily up to + 100° C. Electrically non-conductive.
Rail tanker unloading of petroleum based products
LTW 75 (hose), MKX 75 ('TW' female coupler with Spannfix clamps), Adapter KWZ x VK 80 (51/2" x 'TW'-male coupler)
Boat refuelling: ZVA Slimline 2
Netherlands
LPG 200 / LPG 100
Bunkering hoses for L.P. Gas with SFC flanged hose couplings
UTS hose assembly
Colour production plant
Equipment truck for dangerous goods accidents
suitable hose assemblies and adapters from Elaflex, ELAFLEX_Information_2.17E.pdf
Universal hose assembly UTL 63 with VC 63-3" SS / SS and MK-A 80 SS
ZVA Slimline 2 LT & ZVA Slimline 2 GR LT nozzles
Use of special seals for cold regions
IBC loading
Elaflon Plus FEP hose assembly
Double Closing Safety Swivel Break
SSB 25 DC
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
Rail tanker toploading, TW 100 hose assemblies
HD-C LT, Low Temperature
Antarctica: Low Temperature aircraft refuelling hoses in action; fuel transfer from drums via mobile pump
Forklift refuelling with LPG (L.P. Gas, Autogas)
GasGuard nozzle, LPG 16 hose
ZVA Slimline 2
Automatic nozzle DN 19, for flowrate max. 80 l / min.
Check Valve 350 bar
for Hydrogen
ERV-GR ... ZS
"Green Band" Rubber Expansion Joints with limiters in chemical pumping system
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Contour check
