Cabinet of road tanker:
MK 80-32 TW coupler with bent lever, VB 80 P dust plug
Offshore oilrig: TW hose assemblies, DDC Dry Disconnect Couplings
Hose Reels group picture
Movable, pneumatic rewind system, active Vapour Recovery (VR) for gasoline fuels
Aircraft refuelling hose with reflecting stripes, Hose Beads 'BD' which notably improve the handling as they reduce friction against the tarmac, next generation overwing nozzle ZVF 50
DDC-M 25-1" SS
MannTek Dry Disconnect Coupling, DN 25, stainless steel
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting
Coloured hose assemblies for the forecourt
Slimline 21, M 21-1" NR
Adapters / couplers for vehicles fighting dangerous goods incidents:
Dry Disconnect Stanag 3756 DDC- M 50 / 65 / 80 SS NOT x VK 50 SS/Vi Hose sided MK coupling can be coupled without tools
KR 50 - 21/2"
Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors
ERV-G 50x160
Fuel mixer / blender
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly, bonding cable
Forklift refuelling with LPG (L.P. Gas, Autogas)
GasGuard nozzle, LPG 16 hose; dispenser
ELAFLEX Hamburg
Hose assemblies, marking after testing on the fitting
SG 1" - SSB 16 Propeller
Sight Glass with SSB 16 Safety Break. Compact and lightweight combination of the functions hose swivel, Safety Break and Sight Glass (with propeller).
Storz Safety Couplings Type SHK
upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.
ZVA_AdBlue®_LV_2-Stufen-Anschlag_Step1
Use - 1/2
Ship bunkering
FHD hose assembly, flange connection
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Manufacturing nozzle seat
MannTek DGC-M & DGC-V DryGasCouplings
the alternative to ACME and flanged connections
ELAFLEX Hamburg
Assembling ERV large DN
ZVA Slimline 2 nozzles special version, Slimline dispensing hoses blue / red
Thailand
Hose assembly TW 63 with VX 63-11/2" and DDC-M 65 Al
TW hose with Dry Disconnect Coupling
Urea solution filling of a car:
ZVA AdBlue® LV, Slimline 16 AdBlue® (blue cover)
ZVA 25 nozzle, Slimline hose assembly
Dispenser for truck refuelling
Elaflon PTFE 38 hose assembly with RMC 38 SS foodstuff fitting
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75, DDC-K 3" SS ADR
Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose. DDC cap with pressure relief at container tank outlet.
HD 100 C Neon, underwing refuelling
Aircraft Dispenser
