Media Library / Images

AN 2 SS

Welding nipple stainless steel

VB 50 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Oasis CV Heavy Duty Check Valves for CNG

ELAFLEX Hamburg

Stock commisioning system

ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid

LeverAssist reduces the hold-open force by 90%, for comfortable refuelling in countries where latching is not allowed

Ball Valve 350 bar

for Hydrogen

ZVA Slimline 2 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

ERV TA:

ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.

ZVG 2 EURO UL nozzle for L.P. Gas / Autogas

with EA 866 scuffguard black and LPG 16 S hose assembly orange

System comparison Camlock Cam Locking Couplings

Industry standard vs. ELAFLEX EASYLOC

VC 75-3" SS / SS

Spannloc threaded hose coupling with BSP male thread / Spannloc of stainless steel

ZVA Slimline 2, SSB 16, Slimline 16 hose assemblies

Maroc

Functioning principle of MannTek DDC Dry Disconnect Couplings

closed - open

BD 63 Hose Beads

to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.

Fire-resistant cover for hoses

ZAF Coax adapter (splitter valve) at petrol station dispenser

Road tanker connection hose to trailer with bend KR 50, HD 50 hose assembly MX 50-2" Ms

ERV-R 80.16 ZS 2

Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

ELAFLEX Hamburg

ERV conductivity test

ELAFLEX quality: section view of a ERV bellows

ERV-OR "Orange Band"

LPG Autogas Adapter (filler inlet) BAYO

Bayonet connection

SMS 19-3/4"

Steam hose couplings of steel to EN 14423. With bolted clamps of hot stamped brass. For saturated steam hoses up to 220° C, compressed air, oxygen, oils up to 25 bar W.P. Hose tail and union nut of steel Zn / Cr.

ELAFLEX Hamburg

Visual quality checks

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapters Foodstuff Couplings to DIN 11851 Female Rd 78 x 1/6 SS x VK 50 SS/Vi, Male Rd 78 x 1/6 SS/Vi x MK 50 SS/Vi

Simultaneous Refuelling/Filling of Diesel and AdBlue®

Picture 3

Fluorline EFL 21

Universal pump hose DN 21 for chemicals, petroleum based products, for propane, butane and other L.P. gases, as well as solvents. Ideal for highly sensitive media such as AdBlue^® urea solution. Temperature range - 40° to + 100° C. Burst pressure > 64 bar.

Ship bunkering with LNG

Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling

ERV Fire Resistance test

Elaflex LTW hose assembly, Matterhorn

Supply of the mountain top station via IBC unloading

AMX 50 PA

Ammoniac hose to EN ISO 5771 for water-free, liquid and gaseous ammonia.
