Media Library / Images

Hose Assemblies with Flange - Elapac seals

On board of an aircraft refueller: TW-hose, Spannloc flanged coupling; flange seal: Elapac.

M-St 50 SSE

Female threaded hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)

ZVA LV for AdBlue® with EA 075 LV

Urea solution (DEF, ARLA 32) for Light Vehicles

Fuel Grade Identification to EN 16942 for ZVA Nozzles

Type EK FGI - attach with Product Badge EK 145

Production MannTek, Sweden

Marine bunkering and cargo hoses

offshore supply

ZVA Slimline 2 GR, SG-COAX, ZVA SLimline 2, SG 1" Al

Multi Product Dispenser with / without vapour recovery; nozzles with Sight Glass

V 19-1" cr

Male ferrule hose coupling EN 14424, reusable. Slimline 19 SF (sulphur free) hose, black.

ZVA Slimline 2, black, guard 3 - side view

DDC-K ADR:

DDC Dust Caps with Pressure Relief Valve to ADR Requirements. These pressurized dust caps PN 10 of aluminium for DDC male adapters on road tankers are much lighter than the PN 25 versions of stainless steel.

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

ERV-BR 100.16

BR Rubber Expansion Joint, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products. Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e. g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR.

Stainless steel Hose Reel spring rewind black, FEP 38, DDC-M 50 SS

Cargo loading / unloading of ship, STW 150, Vapour Line

Italy

Elapharm EPH 25 with DIN 11858 fitting, free of dead spaces

ERV-G 100 TW

Road tanker hose reel, made by Elaflex Italia

with LPG hose assembly

Elaflex hose assemblies, nozzles and Rubber Expansion Joints for the chemical industry

Urea solution filling, truck: ZVA HV for AdBlue® nozzle

Road tanker with hose reel -

Quick change system between ZV 500 and ZVA 32 nozzles via DDC Dry Disconnect Coupling

HD-C, airport depot

Underwing couplings with HD-C hoses for bottom loading of aircraft refuellers at airport depot

CBC-C

Cryogenic Breakaway Coupling for LNG with cable release: before release

ZVA Slimline 2 / ZVA Slimline 2 GR

Petrol station nozzles with and without vapour recovery, hose assemblies

Sample Collection Unit

DDC-M 25 Dry Disconnect Couplings and HD hose assembly for sample collection of aircraft fuel

KR 50 - 21/2"

Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors

ELAFLEX refuelling equipment for CNG and LNG

ElaSil® Silicone hose assemblies DN 13-102

For Pharma, foodstuff and cosmetics industry.
ELS 25 with Camlock Cam Locking Coupling, foodstuff thread and Triclamp.

LNG Refuelling

N-LNG Nozzle, pull back handles to uncouple

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapter Hebelarmkupplungen AVK 50 SS/Vi x VK 50 SS/Vi, AMK 50 SS/Vi x VK 50 SS/Vi, AVK 75 SS/Vi x VK 50 SS/Vi

Elaflon Plus FEP 25

Universal hose ELAFLON PLUS FEP with seamless FEP lining, resistant to all commonly used chemicals, see resistance chart. Suitable for both suction and delivery (Type FEP D = delivery only). W.P. up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° C up to + 100° C, briefly up to 130° C. Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min (open system). Meets EN 12115.
