Media Library / Images

ERV-G

Pump station for fuels

Elaflex hose assemblies

Hose fittings: threaded, flanged, quick couplings, Dry Disconnect Couplings

ERV-G ... TW

Dispenser / hydrant inlet pipe

SMX 50-2"

Female hose coupling of steel with Spannfix clamps

Slimline 21 green

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

FWS composite hose / hose assembly

Type FWS PTFE with male threaded fitting VPH-SS

Elaflex AB, Sweden

Elaflon PTFE 50

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

SSB 32, SSB 25, SSB16

Safety Swivel Breaks (SSB)

Oasis FV103 45° Fill Valve with NC 104 Nozzle, for CNG

RVX 32-11/4 SS

Hose coupling with male foodstuff thread and Spannfix clamps

SPANNFIX pinned Sicherheits Klemmbacken aus aluminium

SX 75 NR Al

Urea loading of a petrol station tank

UTS hose assembly, DDC-M 50 SS Dry Disconnect coupling

ERV-GS

"Yellow Steel" Rubber Expansion Joints / ship engine room; Netherlands

Upstream Oil Industry, TW hose assemblies

Kuwait

Oasis FV103 90° Fill Valve with Bus & Truck Nozzle, for CNG

ELAFLEX Hamburg

Assembling Spannloc hose clamps

ZVA Slimline 2

with Sight Glass

Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)

Slimline 21 black

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

ELAFLEX Hamburg

Narrow aisle stock fittings

M 63 2½" SS, VD 76/63 PU

Hose coupling with female thread

HD 50 reel hose for petroleum based products, VC 50-2" Spannloc clamped male coupling

ELAFLEX Hamburg

MX 63-21/2" Ms

Female coupling for hoses, brass, with Spannfix clamp

VK 80 - 2" IG Ms

TW male coupling brass, with reduced female BSP connection, one piece adapter (special type)

ELAFLEX Hamburg

Coax hose assembling, colours

Slimline 16 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

ZVA Slimline 2 with reduced spout and Slimline hose

here: for gasoline, use in countries without vapour recovery regulation

MannTek, DDC-M 50, DEC-M 38, DDC-M 80, DCC-M 50, DGC-M 80, DAC-M 65, DAC-V 65
