SD / Pyropal 230 saturated steam hose
ERV-G 100.16 SS TA
Yellow Band Rubber Expansion Joint PTFE lining
Urea solution filling of a car: ZVA LV for AdBlue®
GasGuard LPG nozzle GG1EH
used for industrial refueling / attended refueling. With hybrid nose piece − low lever force. Release volume on valve closure: 1,7 cm³.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Machining spouts
Hose Reel with manual rewind blue, TW 100, DDC-M 100 SS
Marine terminal, with grey cabinet, customised
VSR vacuum support ring for ERV Rubber Expansion Joints
to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571
Dantec Production hose
Composite hoses: crimping of a flanged hose coupling
L.P.Gas road tanker
Ship bunkering with LNG
CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media
Composite hose Danoil 7GG, DDC-M Dry Disconnect Coupling, airport depot
Oasis SV104 Sandwich Valve with Air Torque Actuator, for CNG
Rubber Expansion Joint ERV-BR 80.16
BR Expansion Joints, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products (e. g. carbon-blacks). Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e.g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR
Locomotive refuelling
ZV 32 DB nozzle with Renk coupling
ERV-OR 65.25
ORANGE BAND Rubber Expansion Joint for Liquid Petroleum Gas (LPG) acc. to EN 589. For tank trucks and refuelling stations. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically dissipative.
Tank container filling coupling: MK 80-32 SS with VB 80 SS
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
ZVG 2 DISH nozzle for L.P. Gas / Autogas, LPG 16 hose assembly
ZVG 2 DISH
Nozzle for L.P. Gas / Autogas, with 'Italian' Claw Coupling. Pictured: coupling open / closed
BD 63, Hose Beads at airport depot
Vehicle refuelling with LPG (L.P. Gas, Autogas, Propane)
GasGuard GG1 ACME nozzle
Oasis FV103 180° Fill Valve with Bus & Truck Nozzle, for CNG
Rubber Expansion Joint ROTEX 80.16
ROTEX expansion joints suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative.
ELAFLEX refuelling equipment for AdBlue® urea solution
NB-ZVF 50 SR, ER 583 PTL
Nozzle boot f. ZVF 50 with additional spout retainer
MK-A 80 SS
MK 80 SS with active safeguard lever
RS 1 x 11/4 SS
Reducer Female/Male
HD 63 C NEON, TW 75 E NEON
'NEON' type with reflecting bands or NEON marking in spiral form
ERV-GS
"Yellow Steel" Rubber Expansion Joints / ship engine room of a ferry
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting ZVA
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO
