ELAFLEX Hamburg
Assembling Spannfix hose clamps
UTS 200 hose assembly in chemical plant
Italy
ElaSil® Silicone hose assemblies DN 13-102
For for high media purity requirements, easy to clean. Suitable for Pharma, foodstuff and cosmetics industry. Homogeneous hose construction of platinum cured, translucent and phtalate free Silicone (FDA / USP), resistant to kinking and highly flexible. Large temperature range -60° C to +200° C. Available as complete hose assembly with crimped fittings, DN 13 to 102. Here: DN 25 with Camlock Cam Locking Coupling and Triclamp connection
Double Closing COAX Safety Break
CSB 21 DC
Oasis ball valves for CNG
ELAFLEX Hamburg
Forklift loading station
V 16-1" cr
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, red.
ERV-G ... TW
Dispenser / hydrant inlet pipe
Vehicle refuelling with LPG (L.P. Gas, Autogas)
GasGuard GG20 ACME nozzle
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (English)
SMS 19-3/4"
Steam hose couplings of steel to EN 14423. With bolted clamps of hot stamped brass. For saturated steam hoses up to 220° C, compressed air, oxygen, oils up to 25 bar W.P. Hose tail and union nut of steel Zn / Cr.
Rubber Expansion Joint ROTEX 80.16
ROTEX expansion joints suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative.
ZVA Slimline 2 GR nozzles
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, yellow.
ERV-CR
"CR" Rubber Expansion Joints - ballast water treatment skid
Nozzle ZVG 2 ACME, hose assembly LPG 16 orange, nozzle boot NB-ZVG
Assembling Spannloc hose fittings
M 19-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 19 SF hose Sulfur Free, black.
Hose trolleys, HD 100 C
Type HD-C, aviation hose, Aljac bonding reel und Lanyard reel
ZVA Slimline 2 nozzle, yellow
MC 38-11/2" SS
Female hose coupling for hoses, stainless steel, with Spannloc clamps
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO (UL listed)
Truck refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 ACME nozzle, LPG 16 hose
ContiTech Production ERV
Calender - preparation of rubber batch
Swivel EA 075 A f. ZVA HV for AdBlue®
old design
ZVG 2 ACME nozzle for L.P. Gas / Autogas
visible: Magnet within the guard for the dispenser Reed Switch
BD 63, HD 63 C
Aircraft refuelling hoses with ELAFLEX Hose Beads 'BD'. Details see Information 7.17
ERV-GR 80.16
GREEN BAND Rubber Expansion Joint for chemicals, acids, alkalis and aggressive chemical waste water. For oil-contaminated compressed air up to + 90° C. Temperature range (depending on medium) - 20° C up to + 100° C, temporarily up to + 110° C. Electrically non-conductive.
System comparison Camlock Cam Locking Couplings
Industry standard vs. ELAFLEX EASYLOC
