Hose assemblies

for petroleum based products, chemicals, foodstuff and pharmaceuticals, LPG

FWS composite hoses / hose assemblies

Type FWS PP with female threaded fitting, Type FWS PTFE with stainless steel flange

DDC-K 2 1/2" PE

Dust cap for DDC-V Dry Disconnect Couplings;
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation

HD 100 C, hydrant hose

Aircraft dispenser, pit

Heating oil delivery: ZH 50 nozzle, HD reel hose

DAC, Airport Depot

Dry Aircraft Coupling ISO 45 with HD-C hoses for bottom loading of aircraft refuellers at airport depot

ELAFLEX Hamburg

Assembling COAX hose SL 21, with inner vapour hose, for vapour recovery Stage II

Slimline 16 green

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

Vergleich visibility aircraft refuelling hoses - below: "Yellow Band" standard, top: "NEON" new version with reflecting bands

Marking of High Temperature Types ZVA Slimline 2 / ZVA Slimline 2 GR

For regions with exceptionally hot summer conditions which may lead to particularly high fuel temperatures we offer High Temperature (HT) nozzle types, available for ZVA Slimline 2 and ZVA Slimline 2 GR.

Rail tanker unloading of petroleum based products

LTW hose assemblies, TW couplings

Elaflon Plus FEP 25

Universal hose ELAFLON PLUS FEP with seamless FEP lining, resistant to all commonly used chemicals, see resistance chart. Suitable for both suction and delivery (Type FEP D = delivery only). W.P. up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° C up to + 100° C, briefly up to 130° C. Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min (open system). Meets EN 12115.

Elaflex hose assemblies, nozzles and Rubber Expansion Joints for the chemical industry

TW filll adapters:

TWV 7 (VK 50 x MB 80), TWÜ 13 (VK 50 x 21/2" fem.)

Type PCS 50 (Polypal Clean DN 50 mm)

Road tanker with large reel, HD hose assembly, ZV 500 nozzle

PHD-F aircraft refuelling hose

PHD 63 F

Stainless steel couplings with PFA coating, type "...SSE"

Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Cabinet of road tanker:

MK 80-32 TW coupler with bent lever, VB 80 P dust plug

ElaSil® Silicone hose

ELAFIX 40 Anti-Siphon

Magnet adapter for installation in filler necks from DN 40. This adapter allows the refilling of urea solution with ZVA AdBlue HV, without the risk of misfillings. Meets ISO 22241-4. - Version with anti-theft protection -

SPANNFIX pinned safety clamps of aluminium

SX 50 Al

Universal hose assembly

PCS 75 (Polypal Clean DN 75 mm) with MX 75-3" SS and DDC-M 80-3" SS Dry Disconnect Coupling

ZVA Slimline 2

with Sight Glass

LNG Refuelling

LNG truck refuelling with 'N-LNG' Nozzle coupled to fuel, LNG 25 fill hose assembly with cover, bonding cable

ZVG 2 K (Korea)

with EA 866 scuffguard / nozzle talker

TW connecting hoses

airport depot, gantry

Ultra Fast Fill Quick Coupler 350 bar

for Hydrogen

Bellows ERV-GR (Green Band) without flanges, with VSD vakuum support spiral

VSD: to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571

Compact Line HD 50, Hose Reel Spring Rewind

FEP 5O, MannTek DDC-M 5O SS
