VKC 75 SS
TW male hose coupling, stainless steel, one part, with Spannfix clamps, with protecting "K"-Ring
DCC Dry Cryogenic Coupling for LNG
with cap
Composite hose Danoil 7GG, DDC-M Dry Disconnect Coupling, airport depot
ZVA 25 for aircraft refuelling
red plastic cover (scuffguard), decal (sticker) AVGAS, dust cap and ground cable assembly
GasGuard LPG nozzle GG1E
eoconomic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.
UTS hose assembly
on board of a foodstuff road tanker
TW coupling wrenches of brass or steel
EW K 50 Ms, EW K 80 Ms, EW K 100 Ms, EW K 50 St, EW K 80 St, EW TWS 50, EW TWS 80
Oasis 1/2" Ball Valve for CNG
Helicopter refuelling, ZVA 32
ZAF Coax adapter (splitter valve) at petrol station dispenser
Urea solution filling, truck: ZVA HV for AdBlue® nozzle
Oasis SV108_SV104 Sandwich Valves with handle, for CNG
Compact Line HD 50, Hose Reel Spring Rewind
FEP 5O, MannTek DDC-M 5O SS
Section view ERV-G Rubber Expansion Joint
Aircraft refuelling: MannTek sampling unit in hydrant system
ERV TA:
ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.
LNG Refuelling
LNG Safety Break SB-LNG VL und SB-LNG FL
Road tanker reel with HD 50 hose assembly, ZV 500 nozzle
ELAFLEX Hamburg
Coax hose assembling
Oasis CNG refuelling equipment:
Ultra Fast Fill System (Diagram, English)
Rubber Expansion Joint ERV-GS HNBR 80.16
YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.
ERV-R
"Red Band" Rubber Expansion Joints/ water treatment
VR Hose Reel Spring Rewind, ZVA Slimline 2 GR blue
for active Vapour Recovery (VR)
Chains K 160, K 160 SS, K 180 L, K 200, K 200 SS, K 260 L, K 300, K 300 SS, K 360, K 360 SS
Connection between coupling and dust cap / plug
Elaflex hose assemblies, nozzles and Rubber Expansion Joints for the chemical industry
Hose Connection with TW coupling, TSG 3" Sight Glass
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
TSG 3" Rg
tank truck sight glass type TSG 3", one end TW tank truck fl ange according to DIN 28459, other end male thread
ELAFLEX Hamburg
Incoming goods / flanges
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting: melting
AMKC 50 SS
'Camlock' stainless steel steel coupler to EN 14420 - 7 with hose tail and Spannloc clamps
