ZVA Slimline 2 GR, black, guard 3 - top view
Locomotive refuelling
Dispenser, ZV 32 DB nozzles with Renk coupling
MannTek DDC-V 150 F Al, DDC-M 150-6"
IBC unloading
Coupling of chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-reducer RS 60 x 2 SS, directly attached to IBC.
Hose Reel Spring Rewind
HD 25 C, ZVA 25 AF red, GKG 25, EKG 1200
Elaflex hose assemblies, nozzles and Rubber Expansion Joints for the chemical industry
ZVA Slimline 2
with Sight Glass
ELAPHARM and SD Pyropal steam hose
Pharmaceutical production
Ship loading/unloading various media - STW 150 and UTS 150 hose assemblies
VB 80 SSE
TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
DAC-V 65, DAC-M 65
Coupling test facility
Urea loading of a petrol station tank
UTS hose assembly, DDC-M 50 SS Dry Disconnect coupling
Oval flange seal FD 650-3 of ELAPAC 3 mm
ERV-OR 65.25
ORANGE BAND Rubber Expansion Joint for Liquid Petroleum Gas (LPG) acc. to EN 589. For tank trucks and refuelling stations. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically dissipative.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA components
ELAFLEX Hamburg
Slimline dispensing hose SF (sulfur-free)
Fuel producers spend considerable effort in fulfilling the maximum allowed sulfur content. Rubber compounds of this hose type are free of sulphur – ensures that the sulphur content of the fuel is not increased, even if the medium remains for a long time within the hose
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling hall, meterial logistics
ZVA Slimline 2, SSB 16, Slimline 16 hose assemblies
Maroc, motorcycle refuelling
Alternative fuels: B 20 (Diesel with up to 20% Biodiesel), E 85 (Gasoline with up to 85% Ethanol)
ZVA Slimline 2, ZVA Slimline 2 GR
ZVA Slimline 2 GR, ZVA Slimline 2
Petrol station Germany
Chemopal 50 mW
Chemopal chemical hose DN 50 with helix
AKD 19 Hy
CouplingSeal CSM
VX 63 2½" SS NR Al
Hose coupling with male thread, Spannloc aus Aluminium
Fluorflex FXD universal hose assemblies
with inner corrugation for maximal flexibility. Picture 2
ZVA Slimline 2, guard no. 8D, black scuffguard, red product sleeve, SL 16 hose assembly with red colour sleeve
ELAFLEX Hamburg
ELAFLEX stock
ERV VSRV:
ERV with bolted vacuum support ring. For maximal vacuum resistance of the selected ERV. Bolted ring in stainless steel AISI 316 Ti.
Double Closing COAX Safety Break
CSB 21 DC
LNG Refuelling
Venting the tank with Vent Coupling 'VC-LNG'
