Ship bunkering with LNG

CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media

ZVG 2 ACME nozzle for L.P. Gas / Autogas, LPG 16 hose assembly

Slimline 21 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

RS 2 x 78 SS

Reducer Female/Male

FHD 50 special type HIFR

(helicopter in flight refuelling)

ELAFLEX Hamburg

Commissioning / Pick by Voice

AN Rd 78 SS

Welding nipple with foodstuff thread, stainless steel

Oasis BV701 Ball Valve, with air torque actuator AT101, for CNG

DAC-V 65

Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading

DAC-V 65

Aircraft refueller, Dry Aircraft Coupling to ISO 45 for bottom loading

Chemical manifold

FEP 5O, MannTek DDC-M 5O SS

AMKC 50 Ms

'Camlock' brass steel coupler to EN 14420 - 7 with hose tail and Spannloc clamps

Elaflon Plus FEP hose assembly, crimped foodstuff fitting

ZVA Slimline 2, guard no. 8D, black scuffguard, red product sleeve, SL 16 hose assembly with red colour sleeve

ZVA Slimline 2 and ZVA Slimline 2 GR, Slimline hose assemblies

Petrol station, Germany

Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)

ELAFLEX Hamburg

Mini Installation instructions, on request

ERV-W 80.16

WHITE BAND Rubber Expansion Joint for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.

Bonding reel grey, high visibility bonding cable with clamp

ZVA Slimline 2 DSA, Prepay Dispenser

DSA: Pressure Controlled Safety Shut-Off

Ship bunkering

HD hose assembly on dispenser vehicle

VB 80 ADR SS / VB 100 ADR Al with pressure relief

Plug for TW female couplers
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation

ERV-G 150 TW, ERV-G 100 TW, ERV-G 80 TW

Elaflex hose assemblies and Rubber Expansion Joints for petroleum based products

Rubber Expansion Joint ERV-GS HNBR 80.16

YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.

ERV-R 80.16 ZS 2

Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

Vergleich visibility aircraft refuelling hoses - below: "Yellow Band" standard, top: "NEON" new version with reflecting bands

GasGuard GG11R

The GasGuard GG11 Back-Check Valve (GG11R: with additional release screw) should be standard equipment for any LPGas road tanker operator. It is used in conjunction with LPGas bulk refueling nozzles to contain leaks at storage tank fill points. If the fill point proves to be leaking when removing the nozzle it can be left on the tank until corrective action is taken. The driver can move to the next fill point without delay.

Construction site / on site refuelling:

ZVA 500 manual bulk nozzle, HD hose assembly, road tanker

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Production Picture 7
