Media Library / Images

ELAFLEX Hamburg, large new narrow aisle stock 2018 for hoses

ROTEX 80.16

Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative

Petrol station in Singapore

ZVA Slimline 2 nozzle with Splashguard, SSB 16 Safety Break, Slimline hose assemblies

LBS 50 hose assembly for foodstuffs, FDA conform

with RMC 50 SS/SS (DIN 11851 foodstuff threaded coupling and Spannloc clamps of stainless steel)

Composite hose assemblies with 'COPSAFE' , suitable for COP systems (cross-over prevention)

electrical conductivity

Sample Collection Unit

DDC-M 25 Dry Disconnect Couplings and HD hose assembly for sample collection of aircraft fuel

AN 2 SS

Welding nipple stainless steel

ELAFIX 40 Anti-Siphon

Magnet adapter for installation in filler necks from DN 40. This adapter allows the refilling of urea solution with ZVA HV for AdBlue^®, without the risk of misfillings. Meets ISO 22241-4. – Version with anti-theft protection –

VB 50 SS

TW dust plug, stainless steel

ROTEX Rubber Expansion Joints

Locomotive

Stainless steel couplings with PFA coating, type "...SSE"

Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Rubber Expansion Joint ERV-BR 80.16

BR Expansion Joints, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products (e. g. carbon-blacks). Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e.g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR

Composite hose assemblies with 'COPSAFE' , suitable for COP systems (cross-over prevention)

Elaflon PTFE 25

ZVA Slimline 2 GR, Coax hose assembly

Automatic nozzle with vapour recovery, flowrate up to 45 l / min.

ELAFLEX Hamburg

Hose assemblies pressure testing (hydrostatic test)

VB 80 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Helicopter refuelling winter / Canada

ZVF 50, HD 50 C NEON

Terminal, TW hose assemblies and DDC Dry Disconnect Couplings

Stainless steel Hose Reel with pneumatic rewind system, HD 50

ERV Rubber Expansion Joints

Picture 4

Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)

FGN 2 SS

Flange with male thread, stainless steel

ELAFLEX Hamburg

Assembling COAX hose SL 21, with inner vapour hose, for vapour recovery Stage II

Road tanker hose reel, made by Elaflex Italia

with LPG hose assembly

Oasis BV706 ball valves with Code 62 flange and SAE connection, for CNG

Hose Trolley for terminal operations (bunkering, cargo and refinery)

Hose Trolley HTR-T

V 16-1" cr

Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, red.

For long and heavy aviation refuelling hoses: Hose Beads 'BD' to EI 1522 standard

They notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.

AMKC 50 Ms

'Camlock' brass steel coupler to EN 14420 - 7 with hose tail and Spannloc clamps
