ELAFLEX Hamburg
Stock intake quality check – measurements
ZVA Slimline 2, SSB 16, Slimline 16 hose assemblies
Maroc
VR Hose Reel Spring Rewind, ZVA Slimline 2 GR blue
for active Vapour Recovery (VR)
Hose assemblies for petroleum based products
Yellow Band quality with nozzle, TW coupling, flange connection
MK 80 SS, TW couplers stainless steel
Slimline 21 hose assembly with non reattacheable female coupling M 21-1" NR
Elapharm EPH 25 with DIN 11858 fitting, free of dead spaces
ELAFLEX Hamburg
ZVA Slimline 2 GR
ERV-G 400.10
DN 400
Terminal Railtanker
LTW 100, MK 100, VK 100, SBC 100-4, FFBV 100
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
Swivels DG of stainless steel
Swivels serve to avoid hose torsion (increase of life span) and help for easier handling
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
ERV-W 80.16 SS TA
White Band Rubber Expansion Joint with "TA" PTFE lining
ERV-G 100 TW
Slimline hose assembly, section view
Dispenser at the airport
ZVA 25 Avgas for overwing refuelling
ZVG 2 Swivel
Easy rotating swivel EA 820
EA 866 scuffguard: fuel grade identification 'LPG' to standard
The scuffguard for LPG / Autogas nozzles shows the LPG fuel grade marking required by standard, and offers a large advertising space
Polypal Clean hose assembly
Pharmaceutical production
Bonding Reel, HD 100, ZVF 50 JET, Aljac Closed Circuit Sampler
Airfield refueller
ELAFLEX Hamburg
Manufacturing bronze corrugated pipes
System comparison Camlock Cam Locking Couplings
Industry standard vs. ELAFLEX EASYLOC
ZVA HV for AdBlue®, SSB 16 SS / BS 16, SL 16 for AdBlue®
Urea solution (DEF, ARLA 32) for trucks: nozzle, Safety Break / Break Sleeve and hose assembly
BD 63 Hose Beads
to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.
ELAFLEX Hamburg
New narrow aisle stock (2018)
DAC-V 65, DAC-M 65
Coupling test facility
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 DISH nozzle, LPG 16 hose assembly, ARK 19 Safety Break
Sample Collection Unit
DDC-M 25 Dry Disconnect Couplings and HD hose assembly for sample collection of aircraft fuel
