Universal hose assembly for vehicles fighting dangerous goods incidents:
PTFE 50, length 5 mtr., assembled with MKX 50 SS/Vi SS, VKX 50 SS/Vi SS
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
ZVA long term testing
Urea loading of a petrol station tank
UTS hose assembly, DDC-M 50 SS Dry Disconnect coupling
ZVA Slimline 2 for aircraft refuelling
black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly
Construction site / on site refuelling:
ZVA 25 (automatic nozzle), road tanker
Elaflon Plus FEP 25
Universal hose ELAFLON PLUS FEP with seamless FEP lining, resistant to all commonly used chemicals, see resistance chart. Suitable for both suction and delivery (Type FEP D = delivery only). W.P. up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° C up to + 100° C, briefly up to 130° C. Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min (open system). Meets EN 12115.
ZVA Slimline 2 for aircraft refuelling
black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly
Equipment for vehicles fighting dangerous goods incidents:
PTFE 50 Universal hose assemblies - with TW couplings of stainless steel
CHD 32
Lilac Band chemical hose without helix, DN 32
RS 21/2 x3 SS
Reducer Female/Male
Manufacturing warm forged parts
Example SC 150 Spannloc clamp
Bonding Reel grey, high visibility bonding cable
LBS 75 hose assembly for foodstuffs, FDA conform
with VC 50 SS male coupling, Spannloc clamps
Fuel delivery at the petrol station
LTW 75 fuel delivery hose, MKX 80 female TW coupler
Vergleich visibility aircraft refuelling hoses - below: "Yellow Band" standard, top: "NEON" new version with reflecting bands
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapters Foodstuff Couplings to DIN 11851 Female Rd 78 x 1/6 SS x VK 50 SS/Vi, Male Rd 78 x 1/6 SS/Vi x MK 50 SS/Vi
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
Elaflex nozzles, hose assemblies and Rubber Expansion Joints for petroleum based products
FFC 50.16 SS
Fixed flange hose fitting of stainless steel, with Spannloc clamps
Elaflex hoses
TW, PTFE, LPG, FEP, UTS, PCS, CHS
TSVX 50
Hose connectors with double shank of hot stamped brass, with Spannfix safety clamps of hot stamped aluminium.
ERV TA:
ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.
FWS 50 PTFE
Composite hose with PTFE lining
ERV-R
"Red Band" Rubber Expansion Joints; pumping station
ELAPAC FD 174 flange seal
Filling of chemicals with nozzles
UTS hose assemblies, ZVA TD nozzles special type for chemicals
Petrol station in Mexico
ZVA Slimline 2 nozzle, SSB 16 Safety Break, Slimline hose assembly
ELAFLEX Hamburg
Assembling ERV medium DN
Example of a marking of test data (hydrostatic test) of a hose assembly
System comparison Camlock Cam Locking Couplings
Industry standard vs. ELAFLEX EASYLOC
