Functioning principle of MannTek DDC Dry Disconnect Couplings
closed - open
SX 50 SS
Spannfix clamp DN 50 of stainless steel
Oasis FV103 180° Fill Valve for CNG
VC 65-21/2" SS / SS
Spannloc threaded hose coupling with BSP male thread / Spannloc of stainless steel
SBC-C 50-2"
MannTek Safety Breakaway Coupling with cable release, 2" female BSP connection
L.P.Gas home delivery:
LPG 38 hose assembly - Aboveground storage Tank
HD-C, underwing nozzle
Aircraft refueller, large reel with aircraft refuelling hose and underwing nozzle
Rail tanker unloading of petroleum based products
Plant side: FWS PP St/St composite hoses, SG 3" Sight Glasses
SX 75
Spannfix clamp DN 75 of aluminium
Oasis BV708, 1" ball valve / isolation valve, CNG fill post for trailer loading with HC200 Quick Coupler
GW-G, FGN 4" SS, RS 4" x 3" SS, MK 80 SS
f. fire brigade dangerous goods equipment trucks
ROTEX 80.16
Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative
Elapharm EPH 25 with DIN 11858 fitting, free of dead spaces
Hose Trolley
HTR-AF, HD 100 C NEON, HD 10 C
Urea solution for trucks: ELAFIX 40 magnet adapter in filler inlet of AdBlue® tank
Safety against misfuelling (mixup with Diesel)
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
Production MannTek, Sweden
Elapharm EPH 25 OHM-G
ELAPHARM OHM G electrically conductive 'Ω / T', light grey cover. Corresponds to DIN 26055-3 / EN 16820, Type A. FDA conform. Homogeneous elastomer hose construction with smooth, black Teflon® PTFE liner.
ERV-BR 100.16
BR Rubber Expansion Joint, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products. Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e. g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR.
IBC unloading
Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.
HD 100 C NEON, HD 10 C sensing hose
Type HD-C, aviation hose
LTW 75 hose assembly
with MannTek DDC Dry Disconnect Coupling; use eg. as connecting hose for heating oil trailers
Vehicle refuelling with LPG (L.P. Gas, Autogas, Propane)
GasGuard GG1 ACME nozzle
Tank container, Antarctica: HD-LT hose assembly, ZVF 25 LT nozzle
Low Temperature types
DAC-V 65, DAC-M 65
Coupling test facility
M 21-1" cr
Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, black.
DCC Dry Cryogenic Coupling for LNG
Coupling process
Hose assembly TW 63 with SFX 63
TW hose with helix, 'TW' flange with hose tail and Spannfix clamps of aluminium
IBC loading
MannTek DDC-M 50, FWS 50 PTFE
