ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Manufacturing nozzle seat
ZVA Slimline 2 GR
Automatic nozzle with vapour recovery, flowrate up to 45 l / min.
DDC-M 100, TW hose assembly
Rail tanker bottom loading with Dry Disconnect Coupling
Compact Line HD 50, Hose Reel Spring Rewind
FEP 5O, MannTek DDC-M 5O SS
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly with cover hose, bonding cable
ZVA Slimline 2 nozzles, ESB 16 Safety Breaks, Slimline hose assemblies
Paraguay
Type PCS, Polypal Clean
one side with RMC foodstuff fitting / Spannloc clamps stainless steel, other side open (note the inner conductive stripe)
Filling plant for special gasoline types
ZVA 25 solvent type with special seals, Slimline hose assemblies
ERV-W 80.16 SS TA
White Band Rubber Expansion Joint with "TA" PTFE lining
SPANNFIX pinned safety clamps of aluminium
SX 50 NR Al
ZVA Slimline 2, black - bottom view
Dispenser picture to distinguish the three different kinds of Safety Breaks
Hose Break, Pump Break, Nozzle Break
Fluorflex FXD universal hose assembly
extremely flexible PTFE hose with maximum bending radius
ZV 500 for chemials
Bulk filling of Methylene Chloride
Oasis BV 708 1" Ball Valve for CNG
GasGuard LPG nozzle GG20DN
With long connector nut to access 'hard to reach' fill points. "DN": suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure : 1,7 cm³.
Locomotive refuelling
Dispenser, ZV 32 DB nozzles with Renk coupling
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Machining spouts
PHD-F aircraft refuelling hose
PHD 63 F
SG-COAX
Sight Glass for ZVA Slimline 2 GR
Mobile tank for solvents
hose assembly UTS 50 with MKX 50 SS and VB 50 SS
Adapter coupling DGC / ACME
DGC-V 50 x 1 3/4" ACME. Dry Disconnect Couplings are state of the art for the fast and safe loading/unloading for liquefied gas (LPG). Connecting with standard fittings is still possible with adapters, like this one with ACME thread.
Transporter and school bus refuelling with LPG (L.P. Gas, Autogas, Propane)
GasGuard ACME nozzle
ELAFLEX refuelling equipment:
Quality is in the detail.
Connection road tanker to trailer: TW hose assembly, DDC Dry Disconnect Coupling
ZVF 50 JET for aircraft refuelling
ELAFLEX Hamburg
ELAFLEX stock hoses
Compact Line HD 50, Hose Reel Spring Rewind
FEP 5O, MannTek DDC-M 5O SS
Assembling "ZS" tie rods to ERV rubber expansion joints
