Media Library / Images

Tank storage: manifold with DDC Dry Disconnect Couplings, TW hose assemblies

ELAFLEX refuelling equipment:

Quality is in the detail.

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Contour check

Locomotive refuelling

ZV 32 DB nozzle with Renk coupling

UTS hose assembly with AMKC 32 SS and AVKC 32 SS

'Camlock' stainless steel female and male coupling to EN 14420 - 7 with hose tail and Spannloc clamps

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Manufacturing of turned parts

Hosebun® hose saddle 'HSB'

provides for a professional and material-protecting suspension of hose assemblies

Unloading petroleum products at the service station (road tanker to UST)

Connection offset UST filling point: LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance

Oasis FV103 with NC203 P30, Light Duty Fill Valve and Transit Nozzle for CNG

ZVA Slimline 2 GR, Coax hose assembly

Automatic nozzle with vapour recovery, flowrate up to 45 l / min.

Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers

Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant

ELAFLEX Hamburg

Cutting area for dispensing hose

KR 50 - 21/2"

Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

HD 100 C, HD 10 sensing hose

Aircraft Dispenser with DN 100 hose (spiralised marking) and a sensor hose to control the hydrant system.

KW bronze corrugated pipe with cathodic protection

Cathodic protection flexible pipe connector (bronze corrugated pipe) for electrically insulating, cathodically protected installations. Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps - and directly underneath the dispensers

V 16-1" cr

Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, black.

Offshore Methane gas production

UTS / CHS hose assemblies

Elaflex hose assemblies

Hose fittings: threaded, flanged, quick couplings, Dry Disconnect Couplings

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

Oasis BV708, 1" ball valve / isolation valve, CNG fill post for trailer loading with HC200 Quick Coupler

ZVG 2 EURO UL nozzle for L.P. Gas / Autogas

with EA 866 scuffguard black and LPG 16 S hose assembly black

VSR vacuum support ring for ERV Rubber Expansion Joints

to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571

Double Closing COAX Safety Break

CSB 21 DC

KWZ 3" Al

Rail tanker adapter with male thread connection, aluminium

ROTEX 80.16

Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative

ELAFLEX Hamburg

Certificate pressure test

ZV 400, HD hose assembly on road tanker

Storz Safety Couplings Type SHK

upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.

Equipment for vehicles fighting dangerous goods incidents:

PTFE 50 Universal hose assemblies - with TW couplings of stainless steel
